Technical data
Series 61 / 63.
Sizes 55 to 200.
Nominal pressure 350 bar.
Peak pressure 400 bar.
for open circuit.
Features
– Variable double pump with two axial tapered piston rotary groups of bent-axis design for hydrostatic drives in open circuits.
– The flow is proportional to the input speed and to the displacement, and is infinitely variable from qV max to qV min = 0.
– The pump is suitable for direct mounting on the flywheel case in diesel engines.
– One common suction port for auxiliary pump and both circuits.
– A wide range of control instruments is available for different control and regulating functions.
– Individual power controller.
– Integrated auxiliary pump with pressure-relief valve, optionally with additional pressure-reduction valve.
– Power take-off for mounting axial piston and gear pumps.
– Excellent power to weight ratio.
– Long service life.
