Technical data
Sizes from 28 to 160.
Nominal pressure 400 bar.
Maximum pressure 450 bar.
Sizes 250
Nominal pressure 350 bar.
Maximum pressure 400 bar.
Features
––Variable plug-in motor with axial tapered piston rotary group of bent-axis design, for hydrostatic drives in open and closed circuits.
––Far-reaching integration in mechanical gearbox due to a recessed mounting flange located on the center of the case (extremely space-saving construction).
––Easy to install, simply plug into the mechanical gearbox (no configuration specifications to be observed).
––Tested unit ready to install.
––For use especially in mobile applications.
––The displacement can be infinitely changed from Vg max to Vg min = 0.
––The wide control range enables the variable motor to satisfy the requirement for high speed and high torque.
––The output speed is dependent on the flow of the pump and the displacement of the motor.
––The output torque increases with the pressure differential between the high-pressure and low-pressure side and with increasing displacement.
